1. Large amount of baking, a baking 32 plates;
2. Main parts imported, domestic assembly;
3. Heat exchanger: stainless steel, fast heating, long life, high thermal efficiency and energy saving, with safety siren, pre-exhaust and explosion-proof device;
4. Furnace structure: double layer tempered glass is adopted for furnace door, which is easy to transport and install;
5. The original imported Italian combustion machine, with less energy consumption, combustion safety, low emissions and other advantages;
6. Uniformity: strong wind convection, good penetration, more uniform; Three-channel five-stage tuyere adjustment, more convenient to adjust the temperature in the furnace;
7. Durability: the control part is separated from the furnace body, heat insulation, less faults, more durable, the average service life of 10 years.
|
Product name |
32 trays hot air rotary oven (electric) |
32 trays hot air rotary oven（ diesel） |
32 trays hot air rotary oven（gas fired） |
|
Type |
LF-100D |
SZM-50-O |
SZM-50-G |
|
Voltage |
3N380V/50Hz-60Hz |
3N380V/50Hz-60Hz |
3N380V/50Hz-60Hz |
|
Power |
48kw/h |
5L/h |
5L/h |
|
Transmission power |
2.5kw |
2.5kw |
2.5kw |
|
Temperature control range |
350℃ |
350℃ |
350℃ |
|
Production capacity |
100kg/h(Take bread for example.) |
100kg/h(Take bread for example.) |
100kg/h(Take bread for example.) |
|
The frame size |
670*820*1690mm |
670*820*1690mm |
670*820*1690mm |
|
Grill the layer number |
16 layer*2＝32dish |
16 layer*2＝32dish |
16 layer*2＝32dish |
|
Boundary dimension |
2000*1800*2200mm |
2000*1800*2200mm |
2000*1800*2200mm |
|
Dimensions of pan |
400*600mm |
400*600mm |
400*600mm |
|
Weight |
1300kg |
1300kg |
1300kg |
|
Body material |
stainless steel |
stainless steel |
stainless steel |
